All About the SNAPnGO Deluxe Edition

The SNAPnGO Is Easy to Set Up & Go

Don't Miss Out On The Good Things In Life!

The base SNAPnGO weighs only 31 pounds — about the same as a packed suitcase — and folds easily to fit in your back seat or trunk. To set it up, step on the foot pedal to raise the t-bar and snap it into running position, insert the seat post to attach the seat and you’re ready to go!

Easy for Everyone Mobility Scooter

Highly maneuverable and easy to drive, you simply press the right thumb control to go forward or in reverse and squeeze the left brake lever to stop. In addition, the release of the throttle engages an electronic motor brake for smooth stopping and precision control. The mechanical rear brakes will ensure additional stopping power when needed. When darkness falls, front and rear LED lights help keep you safe. It has three speed settings to accommodate various environments and has a rider weight capacity of up to 300 pounds.

The SNAPnGO Deluxe is UL Certified and FAA Approved

The SNAPnGO scooter gets its remarkable power from a detachable 36-volt lithium ion 6.4 ah battery and a potent 250-watt brushless hub motor in the rear axle. Without chains or gears, it quietly delivers enough boost to move adults weighing up to 300 pounds at a comfortable walking speed, with a range of up to 13 miles on a full charge. We designed the SNAPnGO scooter to be a serious, long-lasting mobility tool. It's supported by a durable frame crafted from 6061-T6 aircraft-grade aluminum and powder coated to resist corrosion. A smooth ride and minimal rolling resistance is assured by high-technology 8-inch tires featuring a honeycomb interior developed by the military and guaranteed to never go flat. Braking is smooth and secure, front and rear lights aid visibility and safety. With this scooter, you will gain your independence back!

Two Easy Ways to Charge the Battery

The SNAPnGO scooter offers you two easy and convenient ways to charge the battery. You can use the charge port at the handlebars, or charge directly to the battery. The battery is also removable so you can take the battery inside to charge while leaving the scooter in your vehicle (avoid severe temperatures).

User Manual

Brochure

What's Included

The following items are included when you buy this product:

Scooter
Battery
Battery Keys
Charger
Water Bottle Holder
Seat
Seat Base
Seat Post
Arm Rests
Tool Kit
Pouch
Footrests
Travel Bungee
Manual

KEY FEATURES

Aircraft-quality aluminum frame
Heaviest piece 31 lbs
Rider weight limit 300 lbs
Smooth-riding honeycomb never-flat tires
Removable 36v, 6.4ah lithium-ion battery composed of LG cells：3 lbs. • 3-5 years of useful life • 237 watt-hours • Range up to 13 miles per single charge
Meets FAA requirement for travel mobility scooter
Right thumb throttle, left forward/reverse switch with 3 speed settings
Hand brake activates dual rear drum brakes and electric motor brake
Default electric braking mode when thumb controls are released
Front and rear LED Lights
250-watt electric hub motor (600-watt peak output)
Patented Vertical self-standing and dolly feature saves storage space and enhances portability
Bicycle-style travel seat optional
Deluxe seat with back, swivel seat base and arm rests.; Charge port at handlebars.
UL Certified-Independently certified to meet UL 2272 ANSI/CAN Electrical Systems for Personal E-Mobility Devices

SPECIFICATIONS

Weight: Frame, 31.3 lbs,
Battery: 3.3 lbs,
Standard Deluxe seat: 15.6 lbs (w/o armrests 10.8 lbs.)
Total weight assembled with accessories: 51 lbs.
Speed setting 1: 0-2 mph,
Speed setting 2: 0-4 mph,
Speed setting 3: 0-7 mph
Range: up to 13 miles
Battery: Removable and lockable. Weighs 3 lbs. LG lithium ion, 36V, 6.4Ah meets FAA requirement for travel mobility scooter
Battery cycle life: 1000+ cycles (3-5 years of usage, additional batteries available)
Battery charge time: 2 hours 75%, 3 and half hours 100%
Motor: 250W brushless electric hub motor; 600 watts peak
Material: 6061-T6 aircraft grade, powder coated aluminum
Tires: 8-inch honeycomb never-flat tires
Size: 16"x24”x40" folded
UL Certified-Independently certified to meet UL 2272 ANSI/CAN Electrical Systems for Personal E-Mobility Devices
The intended use of this electric scooter is to provide mobility to people with full use of their upper and lower extremities and who are able to support themselves in an upright position. This product is primarily for indoor use. Outdoor capabilities are limited to hard, flat, and even surfaces such as concrete, black top, and other similar surfaces. This product is not a medical device and is not intended to assist, treat, diagnose, or alleviate any medical condition or disability.
Riders should be able to stand and walk independently and have good vision, strength, coordination and balance to safely operate the Glion SNAPnGO. They must be able to mount or dismount the SNAPnGO scooter without help, or risk of falling. The Glion SNAPnGO is not intended for medical purposes to provide mobility to someone restricted to a sitting position. It is not a medical device nor a wheelchair.

GEOMETRY

Folded Height: 40"
Folded Width: 14" without seat; 19" with seat
Seat to Handlebars Distance: 10.5" - 13"
Seat Height: 32" from ground to top of seat back; 21.5" from ground to front of seat
Deluxe Seat Bottom (LxW): 16" x 18"
Deluxe Seat Back (LxW): 18" x 12"
Scooter Width: 24"
Scooter Height: 36.5"
Scooter Length: 43"

INTENDED USE / NOT A MEDICAL DEVICE

The intended use of this mobility scooter is to provide mobility to persons with full use of their upper and lower extremities and who are able to support themselves in an upright position. This product is primarily for indoor use and outdoor capabilities are limited to hard, flat and even surfaces such as concrete, black top and other similar surfaces. While we understand the scooter’s outdoor capabilities are limited, when driving near uneven obstacles, follow the safety guidelines outlined within the safety section of the user manual.

This product is not a medical device and is not intended to assist, treat, diagnose or alleviate any medical condition or disability.

Glion

Glion SNAPnGO Mobility Scooter Deluxe Edition
